• DY 08R Cinema Speaker

    System Type:

    8” Cinema Surround Speaker

    Frequency Response:

    48Hz – 20k Hz

    Impedance:

    8Ω

    Power Rating (Program ):

    100W

    Sensitivity:

    96dB

    Maximum Peak SP:

    113dB

    Angle of Coverage (horizontal * vertical):

    100°* 80°

    Crossover Frequency:

    3.5khz

    System Components:

    8” * 1 + 1.35” * 1

    Dimensions (H*W*D):

    385*217*340 mm

    Net Weight:

    8.5kg
  • DY 10R Cinema Speaker

    System Type:

    10” Cinema Surround Speaker

    Frequency Response:

    40Hz – 18k Hz

    Impedance:

    8Ω

    Power Rating (Program ):

    250W

    Sensitivity:

    96dB

    Maximum Peak SP:

    124dB

    Angle of Coverage (horizontal * vertical):

    100°* 80°

    Crossover Frequency:

    2.5khz

    System Components:

    10” * 1 + 1.75” * 1

    Dimensions (H*W*D):

    475*274*455 mm

    Net Weight:

    15kg
  • DY 215AW Cinema speaker

    System Type:

    Internal 2-way Cinema Speaker

    Frequency Response:

    35Hz – 20k Hz

    Impedance:

    4Ω/8Ω (4Ω)

    Power Rating (Program ):

    700W

    Sensitivity:

    103dB/112dB (103dB)

    Maximum Peak SP:

    136dB/137dB

    Angle of Coverage (horizontal * vertical):

    80°* 40°

    Crossover Frequency:

    500hz

    System Components:

    15” * 2 + 3” * 1

    Dimensions (H*W*D):

    1280*700*3450 mm

    Net Weight:

    73kg
  • DY 215SW Cinema speaker

    System Type:

    External 2-way Cinema Speaker

    Frequency Response:

    35Hz – 20k Hz

    Impedance:

    4Ω/8Ω

    Power Rating (Program ):

    1000W/100W

    Sensitivity:

    103dB/112dB

    Maximum Peak SP:

    136dB/138dB

    Angle of Coverage (horizontal * vertical):

    90°* 40°

    Crossover Frequency:

    500hz

    System Components:

    15” * 2 + 4” * 1

    Dimensions (H*W*D):

    1674*764*812 mm

    Net Weight:

    95kg
  • DY 118B Cinema subwoofer

    System Type:

    18” Cinema Subwoofer

    Frequency Response:

    28Hz – 500Hz

    Impedance:

    8Ω

    Power Rating (Program ):

    800W

    Sensitivity:

    97dB

    Maximum Peak SP:

    132dB

    Angle of Coverage (horizontal * vertical):

    -

    Crossover Frequency:

    80-150Hz

    System Components:

    18” * 1

    Dimensions (H*W*D):

    980*640*450 mm

    Net Weight:

    50kg
  • DY 218B Cinema subwoofer

    System Type:

    2*18” Cinema Subwoofer

    Frequency Response:

    26Hz – 500Hz

    Impedance:

    4Ω

    Power Rating (Program ):

    1600W

    Sensitivity:

    102dB

    Maximum Peak SP:

    140dB

    Angle of Coverage (horizontal * vertical):

    -

    Crossover Frequency:

    80-100Hz

    System Components:

    18” * 2

    Dimensions (H*W*D):

    1200*760*600 mm

    Net Weight:

    98kg
