Continuous Power (8Ω):

800W*2 CH

Continuous Power (4Ω):

1200W*2 CH

Pulsed Power (2Ω):

1550W*2 CH

Bridging Power (8Ω):

-

SNR:

>95dB

Input Sensitivity:

0.775V

Circuitry Type:

DC-DC converter

Harmonic Distortion:

<0.1%

Damping Factor:

>350

Conversion Rate:

30V/us

Input Impedance:

20KΩ – balanced input / 10KΩ – unbalanced

Dimension (W*D*H):

483*462*88 mm (2U)

Net Weight/Gross Weight:

20kg/24.5kg

Continuous Power (8Ω):

1000W*2 CH

Continuous Power (4Ω):

1500W*2 CH

Pulsed Power (2Ω):

1950W*2 CH

Bridging Power (8Ω):

-

SNR:

>95dB

Input Sensitivity:

0.775V

Circuitry Type:

DC-DC converter

Harmonic Distortion:

<0.1%

Damping Factor:

>350

Conversion Rate:

30V/us

Input Impedance:

20KΩ – balanced input / 10KΩ – unbalanced

Dimension (W*D*H):

483*462*88 mm (3U)

Net Weight/Gross Weight:

21.5kg/25.5kg

Continuous Power (8Ω):

1300W*2 CH

Continuous Power (4Ω):

1950W*2 CH

Pulsed Power (2Ω):

2550W*2 CH

Bridging Power (8Ω):

-

SNR:

>95dB

Input Sensitivity:

0.775V

Circuitry Type:

DC-DC converter

Harmonic Distortion:

<0.1%

Damping Factor:

>350

Conversion Rate:

30V/us

Input Impedance:

20KΩ – balanced input / 10KΩ – unbalanced

Dimension (W*D*H):

483*462*133 mm (3U)

Net Weight/Gross Weight:

25kg/29kg

Continuous Power (8Ω):

1500W*2 CH

Continuous Power (4Ω):

2250W*2 CH

Pulsed Power (2Ω):

2700W*2 CH

Bridging Power (8Ω):

-

SNR:

>95dB

Input Sensitivity:

0.775V

Circuitry Type:

DC-DC converter

Harmonic Distortion:

<0.1%

Damping Factor:

>350

Conversion Rate:

40V/us

Input Impedance:

20KΩ – balanced input / 10KΩ – unbalanced

Dimension (W*D*H):

483*462*133 mm (3U)

Net Weight/Gross Weight:

26kg/30kg
