System Type:

8” Coaxial Speaker

Frequency Response:

35Hz – 19k Hz

Woofer:

8” woofer

Tweeter:

1.45” compression driver

Power Rating (Program / Peak):

100W / 200W

Sensitivity:

92dB

Average SP:

113dB

Peak SP:

119dB

Impedance:

8 ohms

Dimensions (W*D*H):

280*275*389 mm

Net Weight:

12kg

Input Connector:

2 + / 2 – IN  1 + / 1 - THRU

Case:

Advanced Splint

Colour:

Black

System Type:

10” Coaxial Speaker

Frequency Response:

40Hz – 19k Hz

Woofer:

10” woofer

Tweeter:

1.45” compression driver

Power Rating (Program / Peak):

150W / 300W

Sensitivity:

95dB

Average SP:

117dB

Peak SP:

123dB

Impedance:

8 ohms

Dimensions (W*D*H):

308*310*402 mm

Net Weight:

18kg

Input Connector:

2 + / 2 – IN  1 + / 1 - THRU

Case:

Advanced Splint

Colour:

Black

System Type:

12” Coaxial Speaker

Frequency Response:

42Hz – 19k Hz

Woofer:

10” woofer

Tweeter:

1.45” compression driver

Power Rating (Program / Peak):

200W / 400W

Sensitivity:

97dB

Average SP:

122dB

Peak SP:

128dB

Impedance:

8 ohms

Dimensions (W*D*H):

370*375*485 mm

Net Weight:

21kg

Input Connector:

2 + / 2 – IN  1 + / 1 - THRU

Case:

Advanced Splint

Colour:

Black

System Type:

15” Coaxial Speaker

Frequency Response:

35Hz – 18k Hz

Woofer:

15” woofer

Tweeter:

3” compression driver

Power Rating (Program / Peak):

300W / 600W

Sensitivity:

100dB

Average SP:

125dB

Peak SP:

131dB

Impedance:

8 ohms

Dimensions (W*D*H):

450*420*590 mm

Net Weight:

30kg

Input Connector:

2 + / 2 – IN  1 + / 1 - THRU

Case:

Advanced Splint

Colour:

Black
